Materials:
Center conduct : HPB59-1 (Brass) ,Gold-plated
Insulator : PTFE (Teflon)
Materials : HPB59-1 (Brass) ,Nickel-plated
Bulkhead : HPB59-1 (Brass) ,Nickel-plated
O-ring : Silicon rubber
Electronic:
Impedance : 50 Ω
Frequency range : 0~ 2.5GHz
VSWR : ≤1.06 at 1.2 Ghz ,≤ 1.2 at 2.5 Ghz
Insertion loss : ≤0.1 dB at 1.2 Ghz ,≤0.2 dB at 2.5 Ghz
Rated DC voltage : 230V
Insulation resistance : ≥5000 mΩ
Contact resistance : Center Contact...≤3mΩ / Outer Contact. .≤2mΩ
